12V/24V Intelligent Toilet Pump P8008
Published:2018-09-06

Remarks: - We can offer OEM/ODM service. - If you are interested in our products,pls send your requirements to sp005@dgshenpeng.com - Our Facebook is:Shenpeng Pump |
■ Product application
Intelligent toilet without water tank
Heating vertilation air conditioning
Cold water cycle in car
The new energy automotive cooling cycle
The battery cooling and auxiliary heating cycles
Hydraulic torque converter cooling cycle
■ Product information
Ambient temperature:-40 to 125℃
Medium temperature:-40 to 120℃
Medium:Clear water
Using place: Indoor
Weight:0.76Kg
Insulation level:H
Service life:20000 hours
Inlet and outlet:20mm
■ FAQ
●How long is your delivery time?
Sample order is 7~10 days.
Bulk order is 15~20 days.
If there is pumps in stock, it is 2 days.
●How long is your warranty of pump?
Warranty is 2 years, can be repaired or returned free of charge if non-man-made damage.
●What’s the payment method?
Paypal or T/T,L/C .
●What certificates have your pumps passed?
All our products have passed CE, RoHS, Reach.
Parts of pumps met FDA, UL.
■ Specifications
Type | P8008 |
Rated Voltage | 12V / 24V |
Voltage Range | 8-20V / 12-32V |
Max Flow | 41L/min, 41L/min |
Max Lift | 9m / 9m |
Max Noise | 48dB / 48dB |
Motor Type | DC Brushless Motor |
Food Grade(Y/N) | N |
Liquid Temperature | -40-125℃ |
Ambient Temperature | -40-125℃ |
Pump Theory | Centrifugal Pump |
Medium | Clear water |
Protection Level | IP67 |
Using Place | Vehicle, intelligent toilet |
Power Consumption | 72W / 72W |
Service Life | 20000 hours |
OD of inlet | ∅20mm |
OD of Outlet | ∅20mm |
Dimension | 133*102*100mm |
Power supply | Battery / Electric / Solar panel |
Structure | Single-stage |
Material | PPS |
Customized functions | 1, Dry-running protection 2, PWM speed adjustable 3, FG signal output 4, Locked-rotor protection |
Remarks | Not self-priming |
■ Curve
Rated Voltage | Voltage Range | Rated Current | Max Head | Max Flow | Rated Poweer | Max Noise |
V | V | A | m | L/min | W | dB(A) |
12 | 8-20 | 6 | 9 | 41 | 72 | ≤48 |
24 | 12-30 | 3 | 9 | 41 | 72 | ≤48 |
