  • Commercial Vehicle DC Pump P9001

Commercial Vehicle DC Pump P9001

Volt: 24V
Head: 9-15m
Noise: ≤50dB(A)
Speed control ways: PWM
Protection level: IP67
Function: Locked-rotor protection
Medium temperature: 0-120℃



  Remarks:

  - We can offer OEM/ODM service.

  - If you are interested in our products,pls send your requirements to sp005@dgshenpeng.com


          I want to Buy Samples                I want to ask technical questions



Commercial Vehicle DC Pump

brushless 12v pump



■ Product application
   The engine cooling circulation pump
   Motor control cooling cycle of 12M pure electric bus and hybrid bus
   The intellingent bath crock
   The intellingent toilet
   Other sanitary ware. Kitchen aquipment


■ Product information
   Ambient temperature:-40 to 125℃
   Medium temperature:-40 to 125℃
   Medium:antifreeze
   Weight:2.21Kg
   Protection level:IP67
   Insulation level:F
   Service life:15000 hours
   Inlet and outlet:38mm


   ■ FAQ
   ●How long is your delivery time?
     Sample order is 7~10 days.
     Bulk order is 15~20 days.
     If there is pumps in stock, it is 2 days.

   ●How long is your warranty of pump?
     Warranty is 2 years, can be repaired or returned free of charge if non-man-made damage.

   ●What’s the payment method?
     Paypal or T/T,L/C .

   ●What certificates have your pumps passed?
     All our products have passed CE, RoHS, Reach.
     Parts of pumps met FDA, UL.


 Specifications

Type

P9001

Rated Voltage

24V / 24V

Voltage Range

12-32V / 12-32V

Max Flow

120L/min, 180L/min

Max Lift

6.5m / 9m

Max Noise

55dB / 60dB

Motor Type

DC Brushless Motor

Food Grade(Y/N)

N

Liquid Temperature

-40-125

Ambient Temperature

-40-125

Pump Theory

Centrifugal Pump

Medium

Water, antifreeze

Protection Level

IP67

Using Place

Vehicle

Power Consumption

110W / 240W

Service Life

15000 hours

OD of inlet

38mm

OD of Outlet

38mm

Dimension

180.9*156*90mm

Power supply

Battery / Electric / Solar panel

Structure

Single-stage

Material

Al alloy + PPS

Customized functions

1, Dry-running protection

2, PWM speed adjustable

3, FG signal output

4, Locked-rotor protection

Remarks

Not self-priming



Rated Voltage

Voltage Range

Rated Current

Max Head

Max Flow

Rated Poweer

Max Noise

V

V

A

m

L/min

W

dBA

24

12-32

4.6

6.5

120

110

45

310

70-350

0.77

10

180

240

55


brushless 12v dc water pump

Commercial Vehicle DC Pump,vehicle dc pump,vehicle pump,water pump cost car,water pump for car

brushless 12v pump,brushless 12v dc water pump,pressure 24v pump,best 12v water pump
