  • Booster DC Water Pump P4529

Booster DC Water Pump P4529

Volt: 12V/24V
Head: 9-15m
Noise: ≤45dB(A)
Speed control ways:
Protection level: IP68
Function: Locked-rotor protection
Medium temperature: 0-100℃



  Remarks:

  - We can offer OEM/ODM service.

  - If you are interested in our products,pls send your requirements to sp005@dgshenpeng.com


          I want to Buy Samples                I want to ask technical questions



12v dc motor pump


■Product application

  The solar water heater


■Product information

  Ambient temperature:-25 to 70℃

  Medium temperature:-25-100℃

  Medium:clear water,antifreeze

  Using place:Indoor

  Weight:0.5kg

  Protection level:IP68

  Insulation level:E

  Service life:15000 hours

■ FAQ

  ●How long is your delivery time?
     Sample order is 7~10 days.
     Bulk order is 30~35 days.
     If there is pumps in stock, it is 2 days.



   How long is your warranty of pump?
     Warranty is 2 years, can be repaired or returned free of charge if non-man-made damage.



   What’s the payment method?
     Paypal or T/T,L/C .



   What certificates have your pumps passed?
     All our products have passed CE, RoHS, Reach.
     Parts of pumps met FDA, UL.

■ Specifications


Type

P4529

Rated Voltage

12V / 24V   (12volt / 24volt)

Voltage Range

8-20V / 12-30V

Max Flow

19L/min, 22L/min

Max Lift

6.5m / 11m

Max Noise

40dB / 50dB

Motor Type

DC Brushless Motor

Food Grade(Y/N)

N

Liquid Temperature

-25-100

Ambient Temperature

-25-70

Pump Theory

Centrifugal Pump

Medium

Hot or cold water, oil, antifreeze

Protection Level

IP68

Using Place

Indoor / Outdoor

Power Consumption

25W / 52W

Service Life

20000 hours

OD of inlet

1/2 inch

OD of Outlet

1/2 inch

Dimension

142*71mm

Power supply

Battery / Electric / Solar panel

Structure

Single-stage

Material

XYRON PPE

Customized functions

1, Dry-running protection

2, Submersible

3, PWM speed adjustable

4, FG signal output

5, Locked-rotor protection

Remarks

Not self-priming


■ Curve

pump dc 12v


Rated Voltage

Voltage Range

Rated Current

Max Head

Max Flow

Rated Poweer

Max Noise

V

V

A

m

L/min

W

dBA

12

8-20

2

7

19

25

40

24

12-30

2.1

10

24

50

45
