EV Fast Charger cooling pump P6214
Published:2018-06-08
Remarks: - We can offer OEM/ODM service. - If you are interested in our products,pls send your requirements to sp005@dgshenpeng.com - Our Facebook is：Shenpeng Pump Obtain samples / Obtain parameters |
■ Product application
Heating vertilation air conditioning
New energy automotive cooling circuit
■ Product information
Ambient temperature: -40 to 125℃
Medium temperature: -40 to 120℃
Medium:Clear water,antifreeze
Weight: 0.46Kg
Protection level: IP67
Insulation level: H
Service life: 20000 hours
Inlet and outlet: 21.3± 0.3mm
■ Curve
Rated Voltage | Voltage Range | Rated Current | Max Head | Max Flow | Rated Poweer | Max Noise |
V | V | A | m | L/min | W | dB（A） |
12 | 8-16 | 2.7 | 6.5 | 24 | 33 | ≤35 |
■ FAQ
●How long is your delivery time?
Sample order is 7~10 days.
Bulk order is 15~20 days.
If there is pumps in stock, it is 2 days.
●How long is your warranty of pump?
Warranty is 2 years, can be repaired or returned free of charge if non-man-made damage.
●What’s the payment method?
Paypal or T/T，L/C .
●What certificates have your pumps passed?
All our products have passed CE, RoHS, Reach.
Some pumps met FDA, UL.
■ Specifications
Type | P6214 |
Rated Voltage | 12V |
Voltage Range | 8-16V |
Max Flow | 24L/min |
Max Lift | 6.5m |
Max Noise | 35dB |
Motor Type | DC Brushless Motor |
Food Grade(Y/N) | N |
Liquid Temperature | -40-120℃ |
Ambient Temperature | -40-125℃ |
Pump Theory | Centrifugal Pump |
Medium | Water, antifreeze |
Protection Level | IP67 |
Using Place | Vehicle |
Power Consumption | 33W |
Service Life | 20000 hours |
OD of inlet | ∅21.3±0.3mm |
OD of Outlet | ∅21.3±0.3mm |
Power supply | Battery / Electric / Solar panel |
Structure | Single-stage |
Material | PPS |
Customized functions | 1, Dry-running protection 2, PWM speed adjustable 3, Locked-rotor protection |
Remarks | Not self-priming |
